RAM 1500 DT Series - Limited (2019-2023) Grille Kit

Product Code
GK-R1500-02K/GK-R1500-ELITE-02K/GK-R1500-PLUS-02K

From €110.00

To €960.00

RAM 1500 DT Series - Limited (2019-2023) Grille Kit

In stock

€110.00

Find a
Stockist

For an OE quality, auxiliary light installation, the Lazer Grille Integration Kits include bespoke mounting brackets which allow for quick and easy fitting of Lazer High Performance LED lights within the front grille of the most popular road cars, pick-up trucks, and light commercial vehicles. Designed to blend seamlessly within the original styling of each vehicle, the resulting lighting setup remains fully robust and secure, with extra protection against theft.

The RAM 1500 DT Series with Limited Trim kit, designed for 2019-2023 vehicles, includes a pair of Linear-6 High Performance LED driving lights, plus wiring kit, alongside 4x brackets precision-engineered to engage perfectly with the standard centre grille on the vehicle. Made from composite material, known for its excellent strength and UV stability, the brackets are fully weather and chemical resistant to ensure your installation remains in great condition year after year.

The RAM 1500 Limited (2019-2023) Grille Integration Kit is optimised for use with Linear-6 High Performance LED Spotlights. Our warranty does not cover grille mounts which are fitted with non-Lazer Lamps’ branded products.

Where the vehicle has Xenon or LED headlights as standard, it may not be possible to detect a 12V high beam signal. In these instances it will be necessary to complete the electrical installation using a Lazer CAN Interface. For advice on how to check for a 12V high beam signal, please click here.



PAYMENT INFORMATION

Please note all transactions are completed in Euros:
If you plan to reclaim VAT on any purchase and require a VAT receipt from your specific country, you will need to instead purchase through one of our local distributors.

Visa / Mastercard / AmexSecure Payment

DELIVERY – EU CUSTOMERS

Van icon

Goods will be shipped via courier within 2 working days of your order being placed (stock permitting), from Lazer Lamps’ warehouse in Belgium. At the checkout stage you will be given the option for Standard or Express shipping options. For more information visit our Delivery Information page. For lower cost, expedited deliveries, with country-specific VAT receipts, we would always encourage purchases to be made through one of our local distributors.

DELIVERY – EUROPE & REST OF THE WORLD

Global delivery symbol

Please visit www.lazerlamps.com for deliveries required outside of the EU.

RAM 1500 DT Series - Limited (2019-2023) Grille Kit

Bespoke vehicle integration kit for Lazer LED light installation

Custom fit for RAM 1500 DT Series - Limited (2019-2023)

Designed for use with Linear-6 High Performance LED lights

Kit also includes bespoke mounting brackets and two-lamp wiring kit

Brackets made from high strength, UV -stable, composite material

Fully road-legal

5-year warranty

Made in Britain

Technical Specifications
  2x Linear-6 2x Linear-6
Elite

2x Linear-6
Elite+
(Boost /
Low Output Mode)

Voltage Range (DC) 10-32V 10-32V 10-32V
LED Life 50,000 hours 50,000 hours 50,000 hours
Weight 800 gr 800 gr 2x 800 gr
HIGH BEAM FUNCTION
Total Luminous Flux 4500 Lm 8100 Lm 10200 /
5000 Lm
Total Driver 'FOV' Flux † 3204 Lm 5767 Lm 7290 /
3644 Lm
Colour Temperature 5000K 5000K
Number of High Output
LEDs
2 x 6 2 x 12 2 x 12
Power Consumption 42 W 84 W 96 / 48 W
Current Draw (at 14.4V) 2.92 A 5.8 A 7.2 / 3.6 A
CERTIFICATION
High Beam ECE R112 ECE R112 ECE R149
ECE Reference 2x 12.5 2 x 17.5 2 x 12.5 - Low Output Mode
PHOTOMETRIC DATA
Horizontal Beam Angle 56° 64° 84o
0.25 lx Line 698m 796m 849 / 600m
0.5 lx Line 494m 563m 600 / 424m
1 lx Line 349m 398m 424 / 300m
3 lx Line 202m 230m 245 / 173m

† Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's 'field-of-view' defined as an area +/- 45o left/right, and +/- 10o up/down. For more information – click here.

What's Included
  • 1x Grille Mounting Kit
  • 2x Linear-6 LED Lamps
  • 1x Two-Lamp Wiring Kit
  • Installation Instructions
